Datasheet
Yamato PPC-200W-II
IP65 portion control scale
The standard scale for both Economarker and ScaleManager systems. A compact bench scale with a stainless-steel platform, in 20 lb and 40 lb capacities.
Key features
- Standard scale on Economarker and ScaleManager systems
- IP65, washdown capable on battery power only
- 9.1″ × 9.1″ stainless-steel platform
- Runs on 6 D batteries (about 3,000 hours continuous with alkaline) or an optional 110 V adapter
- RS-232 connection to the printer or PC
Specifications
| Model | 20 lb | 40 lb |
|---|---|---|
| Capacity | 20 lb × 0.01 lb | 40 lb × 0.02 lb |
| Minimum weight | 0.04 lb | 0.08 lb |
| Platform | 9.1″ × 9.1″ | |
| Overall size | 9.8″ × 9.8″ | |
| Weight | 8.6 lb | |
| Operating temperature | 14°F to 104°F | |
| Humidity | 30% to 85% | |
| Water resistance | IP65, washdown capable on battery power only | |
| Power | 6 D batteries or optional 110 V adapter. Battery life about 3,000 hours continuous with alkaline. | |
| Interface | RS-232 | |
Works with
- Economarker systems (standard scale)
- ScaleManager systems (standard scale)
- Solo2 printers and ScaleManager PCs over RS-232
Specifications are subject to change without notice.
